:shield: Securing Your Coolify Deployment with CrowdSec Integration

This guide walks you through integrating CrowdSec with your Coolify deployment to provide comprehensive security protection. CrowdSec is a community-powered, open-source intrusion prevention system (IPS) that analyzes server logs in real time, detects suspicious behavior, and automatically blocks malicious IPs using a global threat intelligence network.

:magnifying_glass_tilted_left: What CrowdSec Provides

  • Real-time threat detection from Traefik access logs
  • Automatic IP blocking for malicious traffic
  • Community threat intelligence sharing
  • CAPTCHA challenges for suspicious users
  • AppSec WAF protection against common web attacks
  • Prometheus metrics for monitoring
  • Global dashboard at app.crowdsec.net (optional)

Pre-requisites:

This guide assumes Coolify is already deployed and running as per the following guide:

:gear: Manual Setup Steps

Step 1: Prepare Server Prerequisites

Ensure your server has the required Coolify directory structure:

# Create required directories
sudo mkdir -p /data/coolify/proxy/dynamic
sudo mkdir -p /data/coolify/ssh
sudo mkdir -p /data/coolify/applications
sudo mkdir -p /data/coolify/databases
sudo mkdir -p /data/coolify/services
sudo mkdir -p /data/coolify/backups

# Set proper permissions
sudo chown -R 1000:1000 /data/coolify

Step 2: Create CrowdSec Configuration Files

Create the CrowdSec configuration directory and files:

# Create config directories
mkdir -p config/crowdsec/db
mkdir -p config/crowdsec/acquis.d
mkdir -p config/crowdsec_logs
mkdir -p config/coolify/proxy

Create config/crowdsec/acquis.yaml:

poll_without_inotify: false
filenames:
  - /var/log/traefik/*.log
labels:
  type: traefik
---
listen_addr: 0.0.0.0:7422
appsec_config: crowdsecurity/appsec-default
name: myAppSecComponent
source: appsec
labels:
  type: appsec

Create config/crowdsec/profiles.yaml:

name: captcha_remediation
filters:
  - Alert.Remediation == true && Alert.GetScope() == "Ip" && Alert.GetScenario() contains "http"
decisions:
  - type: captcha
    duration: 4h
on_success: break

---
name: default_ip_remediation
filters:
 - Alert.Remediation == true && Alert.GetScope() == "Ip"
decisions:
 - type: ban
   duration: 4h
on_success: break

---
name: default_range_remediation
filters:
 - Alert.Remediation == true && Alert.GetScope() == "Range"
decisions:
 - type: ban
   duration: 4h
on_success: break

Step 3: Create Coolify Proxy Configuration Files

Create config/coolify/proxy/docker-compose.override.yml:

# Coolify Proxy Logging Override
# This file enables access logging for Coolify's Traefik proxy

services:
  coolify-proxy:
    command:
      - '--ping=true'
      - '--ping.entrypoint=http'
      - '--api.dashboard=true'
      - '--entrypoints.http.address=:80'
      - '--entrypoints.https.address=:443'
      - '--entrypoints.http.http.encodequerysemicolons=true'
      - '--entryPoints.http.http2.maxConcurrentStreams=250'
      - '--entrypoints.https.http.encodequerysemicolons=true'
      - '--entryPoints.https.http2.maxConcurrentStreams=250'
      - '--entrypoints.https.http3'
      - '--providers.file.directory=/traefik/dynamic/'
      - '--providers.file.watch=true'
      - '--certificatesresolvers.letsencrypt.acme.httpchallenge=true'
      - '--certificatesresolvers.letsencrypt.acme.httpchallenge.entrypoint=http'
      - '--certificatesresolvers.letsencrypt.acme.storage=/traefik/acme.json'
      - '--api.insecure=false'
      - '--providers.docker=true'
      - '--providers.docker.exposedbydefault=false'
      # 🔽 Added log settings
      - '--log.format=json'
      - '--log.level=INFO'
      - '--accesslog=true'
      - '--accesslog.format=json'
      - '--accesslog.filepath=/traefik/access.log'

Create config/coolify/proxy/dynamic/crowdsec-plugin.yml:

http:
  middlewares:
    crowdsec:
      plugin:
        crowdsec-bouncer:
          crowdsecMode: live
          crowdsecLapiHost: 'crowdsec:8080'
          crowdsecLapiKey: 'PASTE_YOUR_KEY_HERE'
          enabled: true

Step 4: Create Docker Compose Overlay

Create docker-compose.overlay.yml to add CrowdSec to your existing Coolify deployment:

# CrowdSec Integration Overlay for Coolify
# This file adds CrowdSec integration to the base Coolify deployment

services:
  # Add CrowdSec service to the stack
  crowdsec:
    image: crowdsecurity/crowdsec:latest
    container_name: coolify-crowdsec
    environment:
      GID: "1000"
      COLLECTIONS: crowdsecurity/traefik crowdsecurity/appsec-virtual-patching crowdsecurity/appsec-generic-rules crowdsecurity/linux
      ENROLL_INSTANCE_NAME: "${CROWDSEC_INSTANCE_NAME:-pangolin-crowdsec}"
      PARSERS: crowdsecurity/whitelists
      ENROLL_TAGS: docker
      ENROLL_KEY: REPLACE_WITH_YOUR_KEY
    healthcheck:
      interval: 10s
      retries: 15
      timeout: 10s
      test: ["CMD", "cscli", "capi", "status"]
    labels:
      - "traefik.enable=false" # Disable traefik for crowdsec
    volumes:
      # crowdsec container data
      - ./config/crowdsec:/etc/crowdsec # crowdsec config
      - ./config/crowdsec/db:/var/lib/crowdsec/data # crowdsec db
      # log bind mounts into crowdsec (platform-specific)
      - /data/coolify/proxy:/var/log/traefik # traefik logs
      - ./config/coolify/proxy/captcha.html:/etc/traefik/conf/captcha.html
    ports:
      - 6060:6060 # metrics endpoint for prometheus
    restart: unless-stopped
    command: -t # Add test config flag to verify configuration
    networks:
      - ${CROWDSEC_NETWORK:-default}

Step 5: Create CAPTCHA Page

Create config/coolify/proxy/captcha.html for the CAPTCHA challenge page:

<!DOCTYPE html>
<html lang="en">
<head>
  <title>CrowdSec Captcha</title>
  <meta content="text/html; charset=utf-8" />
  <meta name="viewport" content="width=device-width, initial-scale=1.0" />
  <style>
    /* Tailwind CSS styles for the CAPTCHA page */
    body { font-family: ui-sans-serif, system-ui, sans-serif; margin: 0; padding: 1rem; height: 100vh; display: flex; align-items: center; justify-content: center; }
    .container { border: 2px solid #000; border-radius: 0.75rem; padding: 1rem; text-align: center; width: 100%; max-width: 500px; }
    .title { font-size: 1.5rem; font-weight: 700; margin: 1rem 0; }
    .icon { height: 6rem; width: 6rem; margin: 0 auto 1rem; }
  </style>
  <script src="{{ .FrontendJS }}" async defer></script>
</head>
<body>
  <div class="container">
    <svg class="icon" fill="black" viewBox="0 0 576 512">
      <path d="M569.517 440.013C587.975 472.007 564.806 512 527.94 512H48.054c-36.937 0-59.999-40.055-41.577-71.987L246.423 23.985c18.467-32.009 64.72-31.951 83.154 0l239.94 416.028zM288 354c-25.405 0-46 20.595-46 46s20.595 46 46 46 46-20.595 46-46-20.595-46-46-46zm-43.673-165.346l7.418 136c.347 6.364 5.609 11.346 11.982 11.346h48.546c6.373 0 11.635-4.982 11.982-11.346l7.418-136c.375-6.874-5.098-12.654-11.982-12.654h-63.383c-6.884 0-12.356 5.78-11.981 12.654z"/>
    </svg>
    <h1 class="title">CrowdSec Captcha</h1>
    <form action="" method="POST" id="captcha-form">
      <div id="captcha" class="{{ .FrontendKey }}" data-sitekey="{{ .SiteKey }}" data-callback="captchaCallback"></div>
    </form>
    <p>This security check has been powered by <a href="https://crowdsec.net/" target="_blank">CrowdSec</a></p>
  </div>
  <script>
    function captchaCallback() {
      setTimeout(() => document.querySelector('#captcha-form').submit(), 500);
    }
  </script>
</body>
</html>

Step 6: Deploy CrowdSec with Coolify

Deploy your Coolify stack with CrowdSec integration:

# Deploy using the overlay file
docker compose -f docker-compose.yml -f docker-compose.overlay.yml up -d

Step 7: Complete Manual Post-Deployment Setup

After deployment, complete the integration:

# 1. Enable Coolify proxy logging (REQUIRED)
cp config/coolify/proxy/docker-compose.override.yml /data/coolify/proxy/
docker restart coolify-proxy

# 2. Get the bouncer API key
docker exec coolify-crowdsec cscli bouncers add traefik-bouncer

# 3. Update the CrowdSec plugin with your API key
sed -i 's/PASTE_YOUR_KEY_HERE/YOUR_ACTUAL_API_KEY/' config/coolify/proxy/dynamic/crowdsec-plugin.yml

# 4. Copy CrowdSec plugin files to Coolify
cp config/coolify/proxy/dynamic/crowdsec-plugin.yml /data/coolify/proxy/dynamic/
cp config/coolify/proxy/captcha.html /data/coolify/proxy/

# 5. Restart Coolify proxy to apply changes
docker restart coolify-proxy

:wrench: Understanding the Integration

How CrowdSec Works with Coolify

  1. Log Collection: Coolify’s Traefik proxy writes access logs to /data/coolify/proxy/access.log
  2. Log Analysis: CrowdSec container monitors these logs for suspicious patterns
  3. Decision Making: When threats are detected, CrowdSec creates blocking decisions
  4. Enforcement: The CrowdSec Traefik plugin queries the CrowdSec API and blocks malicious IPs
  5. User Experience: Suspicious users may see a CAPTCHA challenge before accessing your sites

Key Components

  • CrowdSec Container: Runs threat detection and maintains the decision database
  • Traefik Plugin: Integrates with Coolify’s proxy to enforce blocking decisions
  • Access Logs: Enable Traefik to log all HTTP requests for analysis
  • CAPTCHA Page: Provides a user-friendly challenge for suspicious traffic

:test_tube: Testing Your CrowdSec Integration

Step 1: Verify CrowdSec is Running

# Check CrowdSec container status
docker ps | grep crowdsec

# Check CrowdSec metrics
docker exec coolify-crowdsec cscli metrics

# Verify log parsing
docker exec coolify-crowdsec cscli metrics | grep -A 10 "Local API Metrics"

Step 2: Test Blocking Functionality

# Manually block an IP for testing
docker exec coolify-crowdsec cscli decisions add -i 1.2.3.4 -d 10m

# View active decisions
docker exec coolify-crowdsec cscli decisions list

# Remove the test block
docker exec coolify-crowdsec cscli decisions delete -i 1.2.3.4

Step 3: Monitor Real Traffic

# Watch access logs being generated
tail -f /data/coolify/proxy/access.log

# Monitor CrowdSec alerts
docker exec coolify-crowdsec cscli alerts list

# Check bouncer metrics
docker exec coolify-crowdsec cscli bouncers list

:bar_chart: Monitoring and Management

CrowdSec Console Dashboard

If you enrolled your instance with CrowdSec.net, you can monitor your deployment at:

  • Dashboard: app.crowdsec.net
  • View blocked IPs, attack patterns, and global threat intelligence
  • Configure alerts and notifications
  • Share threat intelligence with the community

Local Monitoring

# View real-time metrics
docker exec coolify-crowdsec cscli metrics

# Check parser status
docker exec coolify-crowdsec cscli parsers list

# View collections
docker exec coolify-crowdsec cscli collections list

# Monitor hub updates
docker exec coolify-crowdsec cscli hub update

:locked: Security Best Practices

Recommended Configuration

  1. Enable enrollment with CrowdSec.net for threat intelligence
  2. Monitor logs regularly to ensure proper parsing
  3. Update collections periodically for new threat signatures
  4. Configure alerts for critical security events
  5. Test blocking functionality regularly

Network Security

  • CrowdSec API runs on port 8080 (internal to Docker network)
  • Prometheus metrics available on port 6060 (optional monitoring)
  • All communication between Traefik and CrowdSec uses host.docker.internal

:police_car_light: Troubleshooting

Common Issues

Coolify no longer accessible:

# Check that you have created the bouncer
docker exec coolify-crowdsec cscli bouncers list

# Check on the crowdsec console that you have accepted the enrolment for this engine

CrowdSec not parsing logs:

# Check if access.log is being created
ls -la /data/coolify/proxy/access.log

# Verify log format
tail /data/coolify/proxy/access.log

# Check CrowdSec acquisition status
docker exec coolify-crowdsec cscli metrics | grep -A 5 "Acquisition Metrics"

Traefik plugin not working:

# Verify plugin configuration
cat /data/coolify/proxy/dynamic/crowdsec-plugin.yml

# Check Traefik logs
docker logs coolify-proxy

# Verify bouncer API key
docker exec coolify-crowdsec cscli bouncers list

CAPTCHA page not displaying:

# Check if captcha.html exists
ls -la /data/coolify/proxy/captcha.html

# Verify Traefik can access the file
docker exec coolify-proxy ls -la /traefik/captcha.html

:bullseye: What You’ve Achieved

After completing this setup, you now have:

:white_check_mark: Comprehensive threat protection for all Coolify-hosted applications
:white_check_mark: Real-time log analysis and automatic IP blocking
:white_check_mark: CAPTCHA challenges for suspicious users
:white_check_mark: Community threat intelligence integration
:white_check_mark: AppSec WAF protection against common web attacks
:white_check_mark: Scalable security that works with unlimited domains
:white_check_mark: Professional monitoring via CrowdSec dashboard

Your Coolify deployment is now protected by enterprise-grade security that automatically adapts to new threats and shares intelligence with the global CrowdSec community.

:books: Additional Resources

2 Likes
