@ fhptech published Kubernetes Manifest for Traefik Log Dashboard
His Post.
We are running Traefik as part of our Kubernetes deployment (vSphere with Tanzu) and recently deployed the log dashboard to monitor the access logs. Thought I would share this manifest as a POC reference for others or if you wanted to use it as a template for inclusion as another installation option. Excuse any mistakes in the manifest and the use of multiple containers per deployment which goes against standard Kubernetes practices as it was slapped together quickly just to get operational. It includes publishing the frontend via Traefik IngressRoutes
apiVersion: apps/v1
kind: Deployment
metadata:
labels:
app.kubernetes.io/part-of: traefik-log-dashboard
name: traefik-log-dashboard
spec:
replicas: 1
selector:
matchLabels:
app.kubernetes.io/part-of: traefik-log-dashboard
strategy:
type: Recreate
template:
metadata:
labels:
app.kubernetes.io/part-of: traefik-log-dashboard
spec:
containers:
- image: ghcr.io/hhftechnology/traefik-log-dashboard-backend:latest
imagePullPolicy: Always
name: traefik-log-dashboard-backend
env:
- name: NODE_ENV
value: production
- name: PORT
value: "3001"
- name: TRAEFIK_LOG_FILE
value: /logs/traefik
volumeMounts:
- name: traefik-logs
mountPath: /logs/traefik
- image: ghcr.io/hhftechnology/traefik-log-dashboard-frontend:latest
imagePullPolicy: Always
name: traefik-log-dashboard-frontend
env:
- name: NODE_ENV
value: production
- name: BACKEND_SERVICE
value: traefik-log-dashboard-backend
- name: BACKEND_PORT
value: "3001"
volumes:
- name: traefik-logs
nfs:
server: nfs.contoso.com
path: /nfsvol/traefik/logs
restartPolicy: Always
---
apiVersion: v1
kind: Service
metadata:
labels:
app.kubernetes.io/part-of: traefik-log-dashboard
name: traefik-log-dashboard-backend
spec:
selector:
app.kubernetes.io/part-of: traefik-log-dashboard
ports:
- protocol: TCP
port: 3001
targetPort: 3001
---
apiVersion: v1
kind: Service
metadata:
labels:
app.kubernetes.io/part-of: traefik-log-dashboard
name: traefik-log-dashboard-frontend
spec:
selector:
app.kubernetes.io/part-of: traefik-log-dashboard
ports:
- protocol: TCP
port: 80
targetPort: 80
---
apiVersion: traefik.containo.us/v1alpha1
kind: IngressRoute
metadata:
name: traefik-log-dashboard-http
namespace: default
spec:
entryPoints:
- web
routes:
- match: Host(`traefik-log-dashboard.contoso.com`)
kind: Rule
services:
- kind: Service
name: traefik-log-dashboard-frontend
port: 80
middlewares:
- name: redirect-https
---
apiVersion: traefik.containo.us/v1alpha1
kind: IngressRoute
metadata:
name: traefik-log-dashboard
namespace: default
spec:
entryPoints:
- websecure
routes:
- match: Host(`traefik-log-dashboard.contoso.com`)
kind: Rule
services:
- kind: Service
name: traefik-log-dashboard-frontend
port: 80
tls:
secretName: traefik-tls-cert
